Spec

• Length from inlet to outlet, cm (inch): 18.5 (7.3)
• Minimum clearancecm (inch): 268 (105.4)
• Diameter, cm (inch): 45.7 (18.0)
• Weight, kg (lb): 151 (332)
• Height, cm (inch): 155 (60.9)
• Seal material: Silicone
• Configuration material: 316L Stainless Steel
• Brand name: Millistak+
• Cartridge to ***: Three 16-inch diameter module
• Form: T-type
• Installation: Legs
• Connection, Housing head and base: Bolt
• Connection, Vent/drain: 1-1/2in. sanitary flange - ISO DN32
• Connection, Inlet/outlet: 2in. sanitary flange ISO DN40
• Connection, Pressure gauge port: 1-1/2in. sanitary flange- ISO DN32
• Quantity/box: 1
• Overview: Millistak+ (Millistak+) 3 x 16 in. module housing
• Product name: Millistak+ cartridge housing
• Operation temperature range, ℃: -10?135
• Maximum input pressure, kPa (psi): -103 to 1000 (-15 to 145)
• Surface finish, Outside: Electrolytic polishing
• Surface finish, Wetted side: Electrolytic polishing; Ra


  0.8μm
• ※We ask for your kind understanding that lead time might change If it is out of stock in Japan.
