Spec

• Model number: AFG -2005
• Frequency range: 0.1Hz to 5 MHz
• Resolution (Hz): 0.1
• Accuracy: Stability/±20 ppm, Aging Rate/±1 ppm/year, Tolerance/≦ 1 MHz
• Output waveform: sine wave, square wave, ramp wave, noise, ARB (arbitrary waveform)
• Optional waveform function: Amplitude resolution/10 bit, Sample rate/20mS/s (MAX), Wavelength memory length/4 K point
• Frequency response: 0.1Hz to 1MHz (triangular wave and ramp wave)
• Amplitude: 1 mVpp to 10 Vpp (50 ohm load), 2mVpp to 20 Vpp (open circuit), 20 to 25 MHz/1 mVpp to 5 Vpp (50 ohm load), 2mVpp to 10 Vpp (open circuit)
• View: 3.5 inch LCD
• Memory: Panel setting/ARB waveform/each 10 pieces
• Interface: USB
• OS: Windows (R) XP/Vista (R)/7 (32 bit and 64 bit)
• Power supply : AC100 to 240 V 50/60Hz
• Power Consumption : about 25 VA (MAX)
• Size: 266 x 293 x 107mm
• Weight: about 2.5kg
• Accessories: BNC-BNC cable (GTL -110 m) x 1 piece software
• Accessories: Calibration certificates
• *Products with calibration certificate is a service where equipment is calibrated and calibration certificate is issued at the time of shipment.
• *At the time of shipment, we have attached 3 items of "frequency display", calibration certificate test results report and Traceability System Chart.
• *This is ASONE's original certificate attachment service.
