1-2758-01 Function Generator 0.1Hz - 5mhz AFG-2005
Product Description
Product Model: 1-2758-01Product Brand: GW INSTEK (TEXIO […]
Contact Us
Product Details
Product Model: 1-2758-01
Product Brand: GW INSTEK (TEXIO TECHNOLOGY CORPORATION)
Features
- Frequency, amplitude, DC offset, and parameters can be displayed simultaneously.
- Remote control and waveform data can be received from a computer.
Spec
- Model number: AFG-2005
- Frequency range: 0.1Hz - 5MHz
- Resolution (Hz): 0.1
- Accuracy: Stability/±20ppm, Aging rate/±1ppm/year, Tolerance/≦ 1MHz
- Output waveform: Sine wave, square wave, ramp wave, noise, ARB (arbitrary waveform)
- Arbitrary waveform function: Amplitude resolution/10 bits, Sample rate/20ms/s (MAX), Wavelength memory length/4K points
- Frequency characteristics: 0.1Hz - 1MHz (triangular wave, ramp wave)
- Amplitude: 1mVpp - 10Vpp (50Ω load), 2mVpp - 20Vpp (open circuit), 20 - 25MHz/1mVpp - 5Vpp (50Ω load), 2mVpp - 10Vpp (open circuit)
- Display: 3.5 inch LCD
- Memory: Panel setting, ARB waveform/10 pieces each
- Interface: USB
- Supported OS: Windows(R) XP/Vista(R)/7 (32 bit, 64 bit)
- Power supply: AC 100 - 240V, 50/60Hz
- Power consumption: Approximately 25VA (MAX)
- Size: 266 x 293 x 107mm
- Weight: Approx 2.5kg
- Accessories: BNC-BNC cable (GTL-110, 1m) x 1 cable (AFG-2005 - 2025)/2 cables (AFG-2105 - 2125), software
