Spec

• Size (mm): 77.8 x 53.2 x 185.7
• Weight (g): 300
• Number of pieces: 1
• Lighting/Receiving optics: d/8 (Diffuse lighting, 8 degrees display), SCI (including specular component), SCE (excluding specular component)
• Light source: LED (full-band balanced LED)
• Sensor: 256 pixel CMOS sensor
• proofing: automatic
• Wavelength interval: 10 nm
• Wavelength range: 400 ~ 700 nm
• Reflectivity range: 0 ~ 200%
• Reflectivity resolution: 0.01%
• Integrating sphere size: 40 mm
• Test Time: Approximately 1 second (SCI + SCE approximately 2.5 seconds)
• Battery: Rechargeable
• Screen: 2.4 inch IPS full-color touchscreen
• Interface: USB, Bluetooth ®
• Software: Android, iOS, Windows ®
• Color space and index
• Reflectivity, CIE-Lab, CIE-LCh, HunterLab, CIE Luv, XYZ, Yxy, RGB
• Color Difference (delta E ab, delta E cmc, delta E 94, delta E 00), WI (ASTM E 313 - 00, ASTM E 313 -73, CIE/ISO, AATCC, Hunter, Taubeberger Stensby), YI (ASTM D 1925, ASTM E 313 - 00, ASTM E 313 -73)
• Blackness (My, dM), Color Resistance, Hue, (ASTM E 313 - 00), Color Concentration CMYK (A, T, E, M), Milm, Mansell, Opacity, Color Intensity
• Light source: A, B, C, D 50, D 55, D 65, D 75, F1, F2, F 3, F 4, F 5, F 6, F 7, F 8, F 9, F 10, F 11, F 12, CWF, U 30, U 35, DLF, NBF, TL 83, TL 84
• Observer angles: 2 degrees, 10 degrees
• Reproducibility: Chromaticity values Maximum: dEab < 0.04, Mean: dEab < 0.03, Within standard deviation delta Eab 0.02 (when white tiles are measured 30 times at 5 second intervals), Reflectivity: Standard deviation < 0.1%
• Measuring diameter/aperture: MAV/phi 8 mm/phi 11 mm, SAV/phi 4 mm/phi 6 mm, MINI 13 mm
• Difference between devices: delta Eab < 0.2 (BCRA Series II, average measurement of 12 tiles, MAV/SCI)
