Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature point: 1 point of 37 degrees Celsius
• Tank internal dimensions (mm): phi 180 x 180
• Material: Body/Stainless (SUS 430), Tank/Stainless (SUS 304)
• Temperature setting range: room temperature + 5 ~ 80 degrees C
• Temperature control accuracy: +/- 2 degrees C
• Heater capacity: sheath heater 750 W
• Temperature Sensor: K thermocouple
• Temperature control system: microcomputer PID control
• Speed: 100 ~ 1200 rpm
• Safety device: overtemperature protection device, overcurrent protection f***
• Timer setting range: 0 ~ 99 hours, 59 minutes
• Mountable thermometer size: phi 7 ~ 10 mm
• Power supply: 100 VAC 50/60 Hz 800 W
• Power cord length: 2.5 m (3 P plug)
• Accessories: Stirrer (Φ8 x 30 mm) x 1
• External dimensions (mm): 260 x 266 (290) x 241 (() includes projections)
• *Drainboards are not included.
• *When stirring the sample directly, do not *** a drainboard and *** a container with a diameter of 100 mm or less.
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *If you would like to request a local IQOQ, please contact us separately. We will need your installation address for the estimate.
