Spec

• Tank Inner Dimension (mm): φ180 x 180
• Material: Body/Stainless Steel (SUS430), Tank/Stainless Steel (SUS304)
• Temperature Setting Range: Room Temperature +5~80°C
• Temperature adjustment accuracy: ±2°C
• Heater Capacity: Sheath Heater 750 W
• Temperature Sensor: K Thermocouple
• Temperature control system: microcomputer PID control
• Speed: 100~1200rpm
• Safety Device: Excess Temperature Rise Prevention Device, Overcurrent Prevention F***
• Timer setting range: 0~99 hours 59 minutes
• Mountable Thermometer Size: φ7~10 mm
• Power: 100 VAC 50/60Hz 800 W
• Power Cord Length: 2.5 m (3P Plug)
• Accessory: Stirrer (φ8 x 30 mm) x 1
• External Dimensions (mm): 260 x 266 (290) x 241(() includes projections)
• *Drainboard is not included.
• *When stirring the sample directly, please *** a container of φ100 mm or less without using a drainboard.
• This product is compatible with the validation service (IQ/OQ). Please contact us.
• *The validation service is a service where installation qualification (IQ) and operation qualification (OQ) are performed at the customer's site and an inspection report is submitted.
