Spec

• Filtration area, m

  ²

  : 1.26
• Length from inlet to outlet, cm (inch): 15.2 (6.0)
• Processing capacity, L: 750
• Length, cm (inch): 86.4 (34)
• (66187): Silicone
• (66189): 1/4in. hose port with double O-ring seal
• Support material: Polypropylene
• Seal material: Silicone
• Device material: Polypropylene
• Vent cap material: Polypropylene
• Material: Modified PVDF
• Application: Parvovirus removal
• Brand name: Viresolve
• Main application: Protein Purification
• Package: Double easy open bag
• Form: Capsule
• Connection, Vent/drain: 1/4in. hose port with double O-ring seal
• Connection, Inlet/outlet: 38mm (1-1/2in.) sanitary flange
• Quantity/box: 1
• Overview: Opticap XLT30 Viresolve NFP 1-1/2in. TC/TC
• Product name: Opticap XLT30 capsule filter
• Maximum Inlet Pressure (psig): 80
• Maximum Inlet Temperature, °C: 25
• T-line/Gauge Port: T-line
• Air diffusion flow rate, 23 °C:


  30mL/min at 340kPa (50psig) water-wet
• Integrity test:


  30mL/min at 340kPa (50psig) water-wet
• Maximum input pressure, kPa (psi): 552 (80) @ 25


  °C
• Maximum differential pressure, kPa (psid): Positive direction - 552 (80); reverse direction - 345 (50)
• Sterilization: Water-wet filter, Liquid cycle for 5 minutes at 340kPa (50psig)Slow exhaust, up to 60 minutes at 123℃
