Electronic/Electrical Parts and Controll Equipments
63-7350-91 TRACOPOWER TMR 2WI 2W Isolated DC-DC Converter Through Hole, Voltage in 9 → 36 V dc, Voltage out ±15V dc TMR 2-2423WI
Product Description
Product Model: 63-7350-91Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-7350-91
Product Brand: TRACOPOWER
Features
- Operating temperature is without derating. 3. Traco 2W SIP Single/Dual Output Regulated Isolated DC-DC Converter - TMR 2WI Series. Ultra-wide 4:1 input voltage range SIP-9 Package Regulated outputs Excellent load and line regulation 1kV input / output isolation Built-in filter meets EN 55022, Class A and FCC,Level A Remote On/Off Control Continuous short circuit protection Non de-rating
Spec
- Quantity:1set(10pieces)
- Output Voltage : ±15V dc
- Input Voltage Range : 9 → 36 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 1.5kV dc
- Power Rating : 2W
- Output Current : ±65mA
- Mounting Type : Through Hole
- Number of Outputs : 2
- Package : SIP
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Series : TMR 2WI
- CODE No.:166-5423
