63-7344-29 ON Semiconductor SMBJ43A, Uni-Directional TVS Diode, 600W, 2-Pin DO-214AA SMBJ43A
model:
63-7344-29
brand:
ON Semiconductor
Product Description
Product Model: 63-7344-29Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-7344-29
Product Brand: ON Semiconductor
Features
- Transient Voltage Suppressors SMT Unidirectional 600W, SMBJ Series, Fairchild Semiconductor. Glass-Passivated Junction 600W Peak Pulse Power Capability Excellent Clamping Capability Low-Incremental Surge Resistance Fast Response Time UL Certificate #E258596 UL94V-0 Flammability Classification
Spec
- Quantity:1bag(50pieces)
- Diode Configuration : Single
- Maximum Clamping Voltage : 69.4V
- Minimum Breakdown Voltage : 47.8V
- Mounting Type : Surface Mount
- Package Type : DO-214AA (SMB)
- Maximum Reverse Stand-off Voltage : 43V
- Pin Count : 2
- Peak Pulse Power Dissipation : 600W
- Maximum Peak Pulse Current : 8.6A
- Number of Elements per Chip : 1
- Minimum Operating Temperature : -55 °C
- Maximum Operating Temperature : +150 °C
- Maximum Reverse Leakage Current : 5µA
- CODE No.:803-2033
