63-7344-06 ON Semiconductor SMBJ28CA, Bi-Directional TVS Diode, 600W, 2-Pin DO-214AA SMBJ28CA
model:
63-7344-06
brand:
ON Semiconductor
Product Description
Product Model: 63-7344-06Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-7344-06
Product Brand: ON Semiconductor
Features
- Transient Voltage Suppressors SMT Bidirectional 600W, SMBJ Series, Fairchild Semiconductor. Glass-Passivated Junction 600W Peak Pulse Power Capability Excellent Clamping Capability Low-Incremental Surge Resistance Fast Response Time UL Certificate #E258596 UL94V-0 Flammability Classification
Spec
- Quantity:1set(50pieces)
- Diode Configuration : Single
- Maximum Clamping Voltage : 45.4V
- Minimum Breakdown Voltage : 31.1V
- Mounting Type : Surface Mount
- Package Type : DO-214AA (SMB)
- Maximum Reverse Stand-off Voltage : 28V
- Pin Count : 2
- Peak Pulse Power Dissipation : 600W
- Maximum Peak Pulse Current : 13.2A
- Number of Elements per Chip : 1
- Minimum Operating Temperature : -55 °C
- Maximum Operating Temperature : +150 °C
- Dimensions : 4.75 x 3.95 x 2.45mm
- CODE No.:802-2326
