Electronic/Electrical Parts and Controll Equipments
63-7343-15 ON Semiconductor SMBJ24CA, Bi-Directional TVS Diode, 600W, 2-Pin DO-214AA SMBJ24CA
model:
63-7343-15
brand:
ON Semiconductor
Product Description
Product Model: 63-7343-15Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-7343-15
Product Brand: ON Semiconductor
Features
- Transient Voltage Suppressors SMT Bidirectional 600W, SMBJ Series, Fairchild Semiconductor. Glass-Passivated Junction 600W Peak Pulse Power Capability Excellent Clamping Capability Low-Incremental Surge Resistance Fast Response Time UL Certificate #E258596 UL94V-0 Flammability Classification
Spec
- Quantity:1set(3000pieces)
- Direction Type : Bi-Directional
- Maximum Clamping Voltage : 38.9V
- Minimum Breakdown Voltage : 26.7V
- Mounting Type : Surface Mount
- Package Type : DO-214AA (SMB)
- Maximum Reverse Stand-off Voltage : 24V
- Pin Count : 2
- Peak Pulse Power Dissipation : 600W
- Maximum Peak Pulse Current : 15.5A
- Number of Elements per Chip : 1
- Minimum Operating Temperature : -65 °C
- Maximum Operating Temperature : +150 °C
- Width : 3.94mm
- CODE No.:166-1913
