Spec

• Filtration area, m

  ²

  : 1.56
• Filter bore diameter, μm: 1.0
• Diameter, cm (inch): 6.9 (2.7)
• Length, Inch (cm): 20 (50)
• Support material: Polypropylene
• Seal material: Silicone
• Device material: Polypropylene
• Material: Hydrophilic PVDF
• Code: Code 0
• Filter brand name: Durapore(R)
• Brand name: Vitipore
• Main application: Food and Beverage;Beer;Bottled Water;Wine
• Form: Cartridge
• Quantity/box: 1
• Overview: Vitipore II cartridge filter 20 in. 1.0μm code 0
• Product name: Vitipore II cartridge filter
• Air diffusion flow rate, 23 °C:


  12.6mL/min @ 480 mbar (7 psig) in water
• Cartridge code: Code 0 (2-222) O-ring
• Bubble point, 23 °C:


  62kPa (9 psig) air with water
• Maximum input pressure, kPa (psi): Forward - 3.5 (50) @ 25℃; 1.7 (25) @ 80℃; 0.35 (5) @ 109℃. reverse - 1.7 (25) @ 25℃, intermittent
• Maximum differential pressure, kPa (psid): Forward - 345 (50) @ 25℃; 172 (25) @ 80℃; 34 (5) @ 109℃. reverse - 172 (25) @ 25℃, intermittent
• Wettability: Hydrophilic
• Sterilization: SIP of 109° for 30 minutes, 100 times; hot water sterilization of 80° for 30 minutes, 50 times maximum
• Total extract: The extractables level was equal to or less than 23


  mg per 10-inch cartridge after 24


  hours in water at controlled room temperature.
• ※We ask for your kind understanding that lead time might change If it is out of stock in Japan.
