63-7327-47 Recom RP20 F 20W Isolated DC-DC Converter Through Hole, Voltage in 36 → 75 V dc, Voltage out 15V dc RP20-4815SF
Product Description
Product Model: 63-7327-47Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7327-47
Product Brand: Recom
Features
- EN60950, UL1950, CSA950. UL recognised. Operating temperature is with derating. Recom 20W Single/Dual Output Regulated Isolated DC-DC Converter - RP20-F Series. Regulated output Extremely compact design - 20W in a 50.8 x 25.4mm package L-C input filters International safety standard design Six sided continuous shield High efficiency (88% typ) Isolation voltage 1.6kVdc Industrial standard package size 2:1 wide input range Input voltage ±1% max Nickel coated copper case
Spec
- Quantity:1set(9pieces)
- Output Voltage : 15V dc
- Input Voltage Range : 36 → 75 V dc
- Input Voltage Nominal : 48 V dc
- Isolation Voltage : 1.6kV dc
- Power Rating : 20W
- Output Current : 1.33A
- Mounting Type : Through Hole
- Number of Outputs : 1
- Minimum Temperature : -40°C
- Maximum Temperature : +85°C
- Length : 25.4mm
- CODE No.:166-9073
