63-7326-39 LEM AKR Series Current Sensor, 5A nominal current, 4 → 20mA output current AKR 5 C420L
Product Description
Product Model: 63-7326-39Product Brand: LEM Features AK […]
Contact Us
Product Details
Product Model: 63-7326-39
Product Brand: LEM
Features
- AK/AKR Series Solid Core. Measurement of ac sinusoidal waveform currents Large aperture Easy to mount. AK - C10 Series. 10 to 50A and 100 to 200A ac self powered current transducers with analogue output Applications include remote monitoring of automation systems, data loggers and panel meter power consumption. AKR - C420L Series. High isolation between primary and secondary circuits Use these products for non linear loads or in "noisy" power environments. AK - C420L Series. RMS voltage output signal High isolation between primary and secondary circuits
Spec
- Quantity:1piece
- Nominal Current : 5A
- Supply Voltage : 24 V dc, 150 V ac
- Mounting Type : Panel Mount
- Frequency Bandwidth : 10 → 400 Hz
- Bore Size : 19mm
- Minimum Operating Temperature : -20°C
- Maximum Operating Temperature : +50°C
- Depth : 23.7mm
- Height : 55.4mm
- Width : 88.9mm
- CODE No.:446-0535
