63-7323-45 Roxburgh EMC KMF Series 70A 500 V ac 60Hz Flange Mount RFI Filter, with Stud Terminals KMF370
Product Description
Product Model: 63-7323-45Product Brand: Roxburgh EMC Fe […]
Contact Us
Product Details
Product Model: 63-7323-45
Product Brand: Roxburgh EMC
Features
- Roxburgh KMF Series. Roxburgh KMF series filters are designed for applications such as machine tools, industrial controls, process controls, mechanical equipment, handling equipment and UPS. Side mounting either external to or inside machines, drives, cabinets and panels Lightweight with a small footprint and IP rated terminal blocks
Spec
- Quantity:1piece
- Maximum Current Rating : 70A
- Maximum Voltage Rating : 500 V ac
- Mounting Type : Flange Mount
- Termination Style : Stud
- Series : KMF
- Operating Frequency : 60Hz
- Length : 312mm
- Depth : 93mm
- Height : 190mm
- Inductance : 4.9 μH
- Leakage Current : 14.5 mA
- Maximum Operating Temperature : +100°C
- Resistance : 1.3mΩ
- Standards Met : UL 1283
- CODE No.:315-1296
