63-7321-30 1kΩ SMD Trimmer Potentiometer 0.25W Top Adjust Bourns 3314 Series 3314J-2-102E
Product Description
Product Model: 63-7321-30Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 63-7321-30
Product Brand: Bourns
Features
- 250mW 4mm Sealed 3314J Series - Cross Slot. Miniature (nominal 4mm square case size) Excellent mounting efficiency Suitable for flow/reflow soldering or hand soldering Ideal for automatic assembly Cross slot top adjuster Meets standard EIA and EIAJ footprint. Bourns® 3314J Series 4mm Square Single Turn Cermet Trimming Potentiometer (Trimpot®)
Spec
- Quantity:1set(500pieces)
- Maximum Resistance : 1kΩ
- Mounting Type : Surface Mount
- Number of Turns : 1
- Orientation : Top Adjust
- Power Rating : 0.25W
- Series : 3314
- Termination Style : J-Hook
- Tolerance : ±20%
- Temperature Coefficient : ±100ppm/°C
- Length : 4.5mm
- Minimum Operating Temperature : -55°C
- Maximum Operating Temperature : +125°C
- CODE No.:167-3557
