Spec

• Unit control only possible # 1: –
• Thermoblock: Aluminum
• Sample volume: 96 x 0.2 mL PCR tube, 8 x 12 or up to 71 x 0.5 mL PCR tube
• Heating Technology: Peltier Element, Triple Circuit Technology
• Temperature control mode: fast, normal, safe
• Block temperature control range: 4–99°C
• Slope Range: –
• Intuitive graphic programming: Yes
• Gradient Temperature Control Range: –
• Block homogeneity 20–72°C: ≤±0.3°C
• Control accuracy: ±0.2°C
• Email Notification: Yes
• Flexible Lid ® Concept: ○
• 2 Year Warranty: Yes
• Silver block: –
• Slope Blocks: –
• The unit can control two other units in the network: Yes
• USB port: Yes
• Block homogeneity 90°C: ≤±0.4°C
• Heating rate: 3°C/second * 2
• Cooling rate: 2°C/sec * 2
• Slope Blocks: –
• Lid Down Slope: flexlid® technology w/TSP
• Lid temperature range: 37–110°C
• Interfaces: CAN_in/CAN_out, Ethernet, USB
• Power: 115 V, 50–60 Hz
• Maximum power consumption: 700 W
• Total weight: 10.9 kg
• Dimensions (W x D x H): 25 x 41.2 x 32.1 cm/9.8 x 16.2 x 12.6in
• Programs per device: >700
• Remote Device Monitoring and Notification (VisioNize®): VisioNize® boxable
• *1 Control from Mastercycler ® nexus, Mastercycler® nexus gradient, Mastercycler® nexus GSX1, Mastercycler® nexus SX1, Mastercycler® nexus GX2, Mastercycler® nexus X2 or Mastercycler® nexus flat
• *Measure in two blocks
