Analyzer, Testing Equipment
61-0167-32 [Discontinued]Biospectrometer Micromeasurement Set 6135 000.905
Product Description
Product Model: 61-0167-32Product Brand: Eppendorf AG Fe […]
Contact Us
Product Details
Product Model: 61-0167-32
Product Brand: Eppendorf AG
Features
- Biospectrometer Basic and micromeasurement cuvette μCuvette G1.0 set item
- Biospectrometer Basic
- Biospectrometer series that can be scanned at continuously variable wavelengths
- Measurements in the ultraviolet and visible wavelength range of 200 ~ 830 nm are possible. Since the measurement wavelength can be freely selected, it has excellent versatility.
- Standard methods for measuring nucleic acids and proteins have been programmed. Beca*** it is compact and can be measured only by equipment, the footprint can be reduced.
- The wavelength can be freely selected in the entire spectral range (Biospectrometer series: 1 nm increments)
- The program is pre-installed, so you can *** it immediately.
- Compact A3 size, no PC connection required
- Data can be exported to a USB memory or PC
- Results can be printed directly (optional thermal printer DPU-S445 required separately)
- Extremely long-life xenon flash lamp
- Help box for displaying instructions for each step in 6 languages (including Japanese)
- Both micromeasurement cuvettes and standard cuvettes can be ***d
- Micromeasurement cuvette μCuvette G1.0
- The μCuvette G1.0 has an optical path length of only 1 mm, 1/10 that of a standard cuvette. This allows the measurement of high concentrations of nucleic acids and proteins, with a minimum sample size of 1.5 μL.
- Measurements with a sample volume of 1.5 ~ 10 μL
- For nucleic acid and protein concentration measurement
- High concentration samples can be measured without sample dilution
- Dedicated for Biophotometer Series and Biospectrometer Series
Spec
- Set Contents: Bio-Spectrometer Basic Body x 1, μCuvette G 1.0 x 1 piece
- Bio-spectrometer Basic
- Light source (light absorption): Xenon flash lamp
- Ray Height: 8.5 mm
- Optical system (absorption): single beam absorption spectrum measurement using a reference beam.
- Detector (Absorption): CMOS photodiode array
- Wavelength Range (Absorption): Scanning (nm): 200 to with 830, 1 nm increments
- Bandwidth (absorption): < 4 nm
- Absorbance measurement range: 0A to 3.0 A (260 nm)
- dsDNA concentration range: 2.5 to 1500 ng/μL
- Interface: USB Master: For USB Memory, Thermal Printer/USB Slave: For PC Connection/RS -232 C: For Thermal Printer
- Size (W x D x H): 295 x 400 x 150 mm
- Weight: 5.4 kg
- continuous wavelength measurement
- Cuvette G 1.0 for Trace Measurement
- dsDNA measurement range: 25 to 1500 ng/μL * 1
- * 1 Recomm***ed concentration range: 50 to 500 ng/μL
- Application example: Nucleic acid/protein concentration measurement
- UV Transmission: > 180 nm
- Wavelength Range: 180 to 2000 nm
- Size (W x D x H): 12.5 x 12.5 x 48 mm
- capacity: 1.5 to 10 μL * 2
- * 2 We recomm*** at least 3 μL for protein concentration measurement.
- Optical path length: 1 mm
- Base absorbance (260 nm): < 0.05 A
- Ray Height: 8.5 mm
- Cuvette for trace measurement
