60-3358-06 ［Discontinued］Membrane Air Dryer DM Type
Product Description
Product Model: 60-3358-06Product Brand: GL Sciences Inc […]
Contact Us
Product Details
Product Model: 60-3358-06
Product Brand: GL Sciences Inc.
Features
- Dry air can be supplied easily and easily by passing compressed air through hollow membrane fibers.
- A set that combines a membrane air dryer, a pressure regulator with a filter, and an activated carbon filter.
- The removed steam is discharged with the purge air.
- When the inlet pressure is 0.39 MPa, the purge ratio is set to 7:3.
Spec
- Processing Air Volume: 1~10NL/min (Including Purge Air)
- Dew point reached: -22°C (dew point at atmospheric pressure at inlet 0.49 MPa)
- Recomm***ed *** air pressure: 0.29~0.68 MPa
- Voltage: 0.97 MPa
- Operating Ambient Temperature: 1~40°C
- Operating Ambient Temperature: 1~40°C
- Pipe Connection: φ6 Tube Connection (One Touch Joint)
- Regulator Setting Pressure Range: 0.05~0.85 MPa
- Maximum working pressure during adjustment period: 1.0 MPa
- Mounting Posture: Floor Mounting Only
- Dimensions: 145 (W) x 130 (D) x 215 (H) mm
- Set Contents
- Regulator with dust filter x 1
- Membrane Dryer DM-05B x 1
- Charcoal Filter x 1
- Polyurethane Tube x 1m
- One Touch Joint for φ6mm x 2
