3-8024-01 ［Discontinued］Portable Digital Microscope (Color Measurement Function) HandyScope
Product Description
Product Model: 3-8024-01Product Brand: Spectra Co-op. F […]
Contact Us
Product Details
Product Model: 3-8024-01
Product Brand: Spectra Co-op.
Features
- High magnification, high pixel, compact microscope equipped with White/UV/IR light source.
- It can be magnified up to 140 times using a 2 megapixel CMOS sensor.
- Simple object color measurement is also possible in combination with a special standard white plate.
- The dedicated software supports video recording as well as still images, and includes binarization processing, length measurement and area calculation, and object color L*a*b* measurement functions.
- It can be ***d on Windows tablets as well as laptops, so it's easy to take out.
Spec
- Model number: HandyScope
- Size: 69 x 47 x 75mm
- Weight: 100g
- Sensor: 1/3 "CMOS
- Pixels: 1600 x 1200 pixels
- Built-in LED light source: White, UV, IR (LED switchable)
- Frame rate: 30 fps
- Field of View: 8 x 9.5mm at 40 x, 2.4 x 3mm at 140 x
- power supply supply: USB bus power
- Supported OS: Windows (R) 7, 8
- monitors: real-time
- capturing: still images, video
- Processing: measurement length, area calculation (*), binarization, scale comment insertion, L * a * b * reflection color measurement
- Languages: Japanese, English, and other optional languages can be added
