3-5537-21 ［Discontinued］Stereomicroscope with Digital Camera 7.5 x to 45 x LED Lighting STZ-161-TLED-HZ
model:
3-5537-21
category:
Analyzer, Testing Equipment
Product Description
Product Model: 3-5537-21 Features The stereomicroscope […]
Contact Us
Product Details
Product Model: 3-5537-21
Features
- The stereomicroscope is equipped with a UVC-compatible digital microscope system.
Spec
- Overall magnification: 7.5 x to 45 x (zoom type)
- LED lighting: LED
- Image sensor: 1/2. 5-inch CMOS
- Power: 100 ~ 240 VAC
- Lens barrel: Three-eye 45 degree tilt barrel
- Working distance: 110 mm (without auxiliary objective lens)
- Number of effective pixels: approximately 5 million pixels
- Maximum number of pixels: Still image/2592 x 1944 (about 5 million pixels), Movie/1920 x 1080 (about 2 million pixels)
- Frame rate: up to 30 fps
- Operating System: Windows 8 or later (32 bit and 64 bit)
- Eyepiece: WF 10 x/20 mm with eyepiece micrometer mounting frame
- Objective: 0.75 x to 4.5 x (zoom lens barrel type)
- Zoom: 1: 6
- Stage: Body/220 x 237 mm (including protrusions), white-filled round stage/phi 80 mm
- LIGHTING DEVICE: EPIDEMIC/TRANSMITTING LED LIGHT SOURCE CONTINUOUSLY DYNAMED
- Size: Approx. 220 x 306 x 367 mm
- Weight: approximately 3.9 kg
