Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 240 degrees Celsius, 9 points x 2
• Internal dimensions (mm): 300 x 300 x 300
• Temperature setting range (deg. C): room temperature + 20 ~ 240
• Convection system: Natural convection/forced convection switching system
• Temperature control system: 3-stage PID control/SSR output
• Functions: Timer function and program function
• Safety device: Overcurrent breaker, indep***ent overrise prevention function, burnout mechanism (heater OFF when sensor is disconnected)
• Storage capacity: 27 L
• Material: Exterior/Steel Melamine Baked Coating, Interior/Stainless Steel (SUS 304)
• External dimensions: 455 x 440 x 650 mm
• Weight: approximately 30 kg
• Power supply: 100 VAC 50/60 Hz 11.5 A (3 P plug)
• Accessories: 2 sets of shelf rails and shelves (load capacity: 15 kg)
• *Do not put combustible materials in the cabinet.
• *If you would like to request a local IQOQ, please contact us separately. We will need your installation address for the estimate.
