Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature points: 9 points at 650 degrees Celsius
• Internal dimensions (mm): 300 x 337 x 300
• Temperature setting range (deg. C): room temperature + 50 ~ 650
• Convection system: Natural convection
• Temperature control system: 3-stage PID control/SSR output
• Functions: Timer function and program function
• Safety devices: Digital temperature setting type indep***ent heat prevention device, Burnout mechanism (Heater OFF when sensor is disconnected), Overcurrent breaker
• Storage capacity: 30 L
• Exterior/Interior: Steel/Stainless Steel (SUS 310)
• External dimensions: 510 x 597 x 820 mm
• Weight: approximately 33 kg
• Power supply: 100 VAC 50/60 Hz (3 P plug) 13.5 A
• Accessories: 2 sets of shelf rails and shelves (load capacity: 15 kg)
• Local validation services (IQ/OQ) are also available.　Please contact us.
• *The on-site validation service is a service that performs installation qualification (IQ) and operational performance qualification (OQ) at the installation site and submits an inspection form.
• *Do not put combustible materials in the cabinet.
• *If you would like to request a local IQOQ, please contact us separately. We will need your installation address for the estimate.
