63-7023-24 Vishay Single Layer Ceramic Capacitor (SLCC) 2nF 40kV dc ±20% N4700 Dielectric 715C Series +85°C Max Op. Temp. 715C40KTD20
Product Description
Product Model: 63-7023-24Product Brand: Vishay Features […]
Contact Us
Product Details
Product Model: 63-7023-24
Product Brand: Vishay
Features
- Vishay 715 C KT Series
- The Vishay 715 C KT Series high voltage capacitors are designed for *** in high power applications. This single-layer capacitor is manufactured from a Class 1 strontium-based ceramic dielectric. Features low inductance and high insulation resistance, and supports screw terminal installation. The capacitance range is 140 pF to 8 nF.
- Features High Insulation Resistance Low Loss Factor: 0.2% @ 1 kHz Epoxy Coating Negligible Level Piezoelectric/Electrostrictive Ceramic Single Layer Capacitor Applications
Spec
- Quantity:1piece
- Capacitance : 2nF
- Voltage : 40kV dc
- Series : 715C
- Tolerance : ±20%
- Dielectric : N4700
- Package/Case : 0814
- Diameter : 60mm
- Height : 31mm
- Dimensions : 60 (Dia.) x 31mm
- Minimum Operating Temperature : -30°C
- CODE No.:131-1210
