63-7019-27 Binder 712 Series M9 Panel Mount Connector, 2 contacts Socket 09-0403-00-02
Product Description
Product Model: 63-7019-27Product Brand: Binder Features […]
Contact Us
Product Details
Product Model: 63-7019-27
Product Brand: Binder
Features
- Panel Plug ; Socket
- Panel plugs and sockets feature a keying groove for anti-rotation so they may be either mounted into the appropriate panel hole (details above) or mounted straight into a 12mm hole (with no key tongue) and fixed with the flange plate kit.
Spec
- Quantity:1piece
- Number of Contacts : 2
- Mounting Type : Panel Mount
- Connector Size : M9
- Termination Method : Solder
- Current Rating : 4A
- IP Rating : IP67
- Contact G***er : Male
- Voltage Rating : 125 V
- Body Orientation : Straight
- Series : 712
- Housing Material : Metal
- CODE No.:129-8949
