61-7656-97 Speed Controller Free Type M3 x 0.5 Clean Package JSS3-M3B-C
Product Description
Product Model: 61-7656-97Product Brand: NIHON PISCO CO. […]
Contact Us
Product Details
Product Model: 61-7656-97
Product Brand: NIHON PISCO CO., LTD.
Features
- Speed control valve for driving equipment.
- After mounting, the tube removal angle can be changed by rotating the metal body and the resin body.
- Fluorine grease is ***d for the grease, and after cleaning with clean air, it is packaged in a clean room (equivalent to ISO class 6).
Spec
- Fluid ***d: Air
- Used pressure range: 0.1 - 0.9 MPa (large flow rate type: 0.1 - 0.7MPa)
- Check valve operating pressure: 0.05MPa
- Operating temperature range: 0 - 60℃ (no freezing)
- RoHS supported
- Applicable tube size (outer diameter): φ3mm
- Applied screw size (metric screw): M3 x 0.5
- Control system: Meter-in control, Lock nut color: Black, Air entered from the fitting side is controlled, Air entered from the screw side is released from the fitting side without any control.
- Flow rate type: Standard, Fitting size (mm): φ3, φ4, Controlled flow rate (?/min (ANR)): 63, Needle rotation speed 7, Primary pressure (Mpa) 0.5
- Package specification: Clean room packaging
- Open ring (material): Light blue (POM)
- Resin body color (material): Light gray (PBT)
- Metal body material (process): Yellow copper (electroless nickel plating)
- Carved seal of needle knob portion: B
Related product recommendations
You may also be interested in the following products
automaticdiluter
64-3297-51 IVALUE Stainless Steel Screwed Y-Shaped Strainer Element 80 Mesh IVL-SYST-ELM8010A
model: 64-3297-51
brand: ISHIGURO
automaticdiluter
65-9007-46 ［Discontinued］TSP Coupler Hose Size Φ25 x Φ33 mm 4±0.4 mm Stainless Steel 633 g 8TSN-250SUSNBR
