63-7003-14 KEMET 15nF Polyester Capacitor PET 63 V ac, 100 V dc ±10% R82 Series R82EC2150Z350K
Product Description
Product Model: 63-7003-14Product Brand: KEMET Features […]
Contact Us
Product Details
Product Model: 63-7003-14
Product Brand: KEMET
Features
- KEMET Miniature R82 Series
- The KEMET R82 Series is a metallized polyester film capacitor with a radial lead made of tin plated wire. The R82 series radial lead is electrically welded to the contact metal layer at the *** of the capacitor winding. This capacitor is enclosed in a thermosetting resin plastic case with self-extinguishing and solvent resistance. The main applications of the R82 series include blocking circuits, coupling circuits, decoupling circuits, timing circuits, and oscillation circuits.
- Features Wide voltage range: 50 → 400 V dc RoHS-compliant and lead-free termination Self-recovery function Capacitance range: 0.001 → 4.7 μF Lead spacing: 5 mm Capacitance tolerance: ± 5%, ± 10%, ± 20% Weather-resistant Category: 55/105/56 Operating temperature range: -55 → +105 °C Tape and reel packaging is available in IEC602862 compliant in-vehicle (AECQ200) grade Applications: Main applications include blocking, coupling, decoupling, timing, and oscillation circuits.
Spec
- Quantity:1bag(50pieces)
- Capacitance : 15nF
- Voltage : 63 V ac, 100 V dc
- Lead Pitch : 5mm
- Series : R82
- Tolerance : ±10%
- Dielectric : Polyester
- Length : 7.2mm
- Depth : 2.5mm
- Height : 6.5mm
- Dimensions : 7.2 x 2.5 x 6.5mm
- Minimum Operating Temperature : -55°C
- Maximum Operating Temperature : +105°C
- Terminal Type : Radial
- CODE No.:126-2277
