63-7001-99 Artesyn Embedded Technologies AXA 25W Isolated DC-DC Converter Through Hole, Voltage in 9 → 36 V dc, Voltage out AXA02B18-L
model:
63-7001-99
brand:
Artesyn Embedded Technologies
Product Description
Product Model: 63-7001-99Product Brand: Artesyn Embedde […]
Contact Us
Product Details
Product Model: 63-7001-99
Product Brand: Artesyn Embedded Technologies
Features
- UL/cUL60950-1, IEC/EN60950-1
- Artesyn AXA series insulated DC/DC converters
- Artesyn AXA series insulated DC/DC converters are packaged in an ultra-compact DIP or SIP package with a low profile thickness of 8 mm. This series features a 87% efficient option with an ultra-wide 4:1 input range. This AXA series has a remote on/off mechanism so you can customize any application. Approved for lead-free reflow soldering in accordance with IPC/JEDEC J-STD-020D.
- Features and Advantages Single Output and Dual Output Ultra-compact DIP/SIP Optional Metal Case with Insulated Baseplate Remote On/Off Capable Input Filter Complies with EN55022, Class A and FCC Level A
Spec
- Quantity:1piece
- Output Voltage : 12V dc
- Input Voltage Range : 9 → 36 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 1500V dc
- Power Rating : 25W
- Output Current : 2.09A
- Mounting Type : Through Hole
- Number of Outputs : 1
- Efficiency : 89%
- Package : 1623
- Load Regulation : ±1%
- Maximum Temperature : +85°C
- Series : AXA
- CODE No.:126-2103
