Spec

• Key Features
• Mounting area reduced by about half compared to conventional products
• Tantalum capacitors and aluminum electrolytic capacitorless
• All series have built-in remote ON/OFF function
• The output voltage is accurate to within +/- 3% (under 10 W single output).
• 5-sided metal shielded low noise design
• Lightweight design without resin filling
• Supports implementation of DIP insertion, SMD mounting, and SIP vertical insertion (3W product)
• Key Specifications
• Output Power 3.96 W
• Input voltage DC 4.5 ~ 9.0 V
• Output voltage DC 3.3 V
• Output Current 1.2 A
• Efficiency (typ) 76%
• Operating temperature range: -40 to + 85 degrees Celsius
• Geometrical landscape DIP type
• Dimensions (mm) 22.86 x 8.5 x 21.1 mm
• RoHS compliant
