63-6969-58 TRACOPOWER TEL 8WI 8W Isolated DC-DC Converter Through Hole, Voltage in 9 → 36 V dc, Voltage out ±12V dc TEL 8-2422WI
Product Description
Product Model: 63-6969-58Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-6969-58
Product Brand: TRACOPOWER
Features
- EN55022 Class A Traco Insulated DC-DC Converter, TEL 8 Series Tracopower Ultra-compact 8 W DIP-16 Metal Package Insulated DC-DC Converter Product. The TEL 8 series has 2.3 times higher power density than the Tracopower TEN 8 series. This results in up to 86% efficiency in the 2:1 power supply input voltage range and a high operating temperature of +70 °C at full load. The Tracopower TEL 8 series also has an input filter to meet the requirements for EN55022 Class A conductive radiation. The Tracopower TEL8 series is a cost-effective product with no performance compromises. This series is suitable for space-limited applications such as IT and industrial electronics.
- Features & Benefits: Wide 2:1 input range with 5.3 W and 8 W options. Equipped with industry standard safety features such as fully adjustable output overload/short circuit protection
Spec
- Quantity:1piece
- Output Voltage : ±12V dc
- Output Voltage Adjustment Range : ±2%
- Input Voltage Range : 9 → 36 V dc
- Input Voltage Nominal : 24 V dc
- Isolation Voltage : 1500 V dc @ 60 s, 1800 V Pk-Pk @ 1 s
- Power Rating : 8W
- Output Current : ±335mA
- Mounting Type : Through Hole
- Number of Outputs : 2
- Efficiency : 85%
- Package : DIP 16
- Load Regulation : 1%
- Maximum Temperature : +80°C
- Depth : 8.5mm
- CODE No.:125-0242
