63-6951-75 RS PRO Panel Mount Connector, 3 Contacts 124-6681
Product Description
Product Model: 63-6951-75Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-6951-75
Product Brand: RS PRO
Features
- 2 Hole Flange Mounting Socket 25 A Round Connector (Screw Type) IP68
- These RS Pro screw plugs are ideal candidates for various applications. This particular model has a large, sturdy shell reinforced with two-hole flange mounting connections. In addition, this industrial connector has an IP68 rating, making it suitable for harsh environments. If you choose a male connector, this version is recomm***ed.
- Features and benefits: 2 pins, 3 pins, 5 pins Allowable outer diameter of cable: 4.5 → 7 mm Screw contact termination High quality nylon 66 shell Panel cutout hole diameter: 21 mm
Spec
- Number of Contacts:3
- Mounting Type:Panel Mount
- Connector Size:Standard
- Plug/Socket:Plug
- Termination Method:Screw
- IP Rating:IP68
- Current Rating:25.0A
- Voltage Rating:500 V
- Mating Type:Threaded
- Body Orientation:Straight
- Housing Material:Polymer
- Contact Material:Brass
- CODE No.:124-6681
