Electronic/Electrical Parts and Controll Equipments
63-6951-71 RS PRO Panel Mount Connector, 2 Contacts 124-6677
Product Description
Product Model: 63-6951-71Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-6951-71
Product Brand: RS PRO
Features
- 2 Hole Flange Mounting Socket 25 A Round Connector (Screw Type) IP68
- These RS Pro screw sockets are ideal candidates for a variety of applications. This particular model has a large, sturdy shell reinforced with two-hole flange mounting connections. In addition, this industrial connector has an IP68 rating, making it suitable for harsh environments. If you choose a female connector, we recomm*** this version.
- Features and Advantages
- Available with 2, 3, and 5 pins Allowed outer diameter of cable: 4.5 → 7 mm Thread contact termination High-quality nylon 66 Shell panel Cutout hole diameter: 21 mm
Spec
- Number of Contacts:2
- Mounting Type:Panel Mount
- Connector Size:Standard
- Plug/Socket:Socket
- Termination Method:Screw
- IP Rating:IP68
- Current Rating:25.0A
- Voltage Rating:500 V
- Mating Type:Threaded
- Body Orientation:Straight
- Housing Material:Polymer
- Minimum Operating Temperature:-25°C
- CODE No.:124-6677
