Electronic/Electrical Parts and Controll Equipments
63-6910-71 0 to 12 V dc DC-DC Converter Insulation type high voltage output type 833 microA 600 V dc Q06-12
Product Description
Product Model: 63-6910-71Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6910-71
Product Brand: XP Power
Features
- UL, RoHS
- XP Power Insulated DC-High Voltage DC Converter A Series
- Q Series DC-High Voltage DC Converter is a highly reliable product despite its ultra-miniature size. This converter is ideal for applications that require small size and lightweight.
- Features and Advantages: Super Miniature Case Size Reliable External Component Free Low Ripple and EMI/RFI Input/Output Proportional Input/Output Insulation Low Leakage Current Coupling Capacitance Low Input/Output Short Circuit Protection Control Pin
- Application:
- Avalanche Photodiode Photomultiplier Tube Light Source Piezo Device Maintaining Ion Pump Electrophoresis Printer Ignition Device Charging Capacitor
Spec
- Quantity: 1 piece
- Output Voltage: 600 V dc
- Input voltage range: 0 to 12 V dc
- Output current: 833 microA
- Mounting type: through hole
- Number of outputs: 1
- Minimum temperature: -25 degrees C
- Maximum temperature: + 70 degrees C
- Ripple Noise: < 0.1% Pk-Pk
- RoHS compliance status: Compliance
- Securities Code: 123 -8429
