Electronic/Electrical Parts and Controll Equipments
63-6910-53 DC-DC Converter Non- Insulation high voltage Type 1 1 microA2 kV 2.4 mW P20P
Product Description
Product Model: 63-6910-53Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6910-53
Product Brand: XP Power
Features
- RoHS
- XP Power DC-High Voltage DC Non-Insulated Converter P-Series
- P-Series Micro Power DC-High Voltage DC Converter is a lightweight product with very low power consumption. The low height of the case makes it ideal for portable, battery-powered devices.
- Features and Benefits: Magnetic Free Ultra Low Noise Design Rectified Miniature Size Metal Case with Earth Programmable Output: 0 to 100% Wide Input Voltage Range Ultra Low Ripple Ultra Low RFI/EMI Voltage Monitor Potentiometer Programming or External Voltage Low Power Consumption Built-in Voltage Reference Soft Start Reliable
- Application:
- Portable Battery Powered CBRN Detector Low Power Electrostatic Instrument Low Power Bias Low Power Piezo Device Low Power Aerosol Device
Spec
- Quantity: 1 piece
- Output Voltage: 2 kV
- Input voltage range: 5 to 12 V dc
- Rating Power: 2.4 mW
- Output current: 1 microA
- Number of outputs: 1
- Minimum temperature: -10 degrees C
- Maximum temperature: + 70 degrees C
- MTBF Average Failure interval: > 1.6 million h
- RoHS compliance status: Compliance
- Securities Code: 123 -8411
