63-6910-30 DC-DC Converter Non- Insulation high voltage Type 1 100 microA 10 kV 1 W CB101
Product Description
Product Model: 63-6910-30Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6910-30
Product Brand: XP Power
Features
- UL, 94V-0, RoHS
- XP Power DC-High Voltage DC Non-Insulated CB Series Converter
- CB series converters are miniature rectified high voltage power supplies. The CB converter is a clean and reliable high voltage shielded PC mounting package. CB series is ideal for small and delicate equipment.
- Features and Benefits: Rectified quasi-sinusoidal oscillator, low noise compact size Programmable output: 0 → 100% high stability 11.5 → 16 V wide input range Ultra-low EMI/RFI reliability case - Insulated case Earthed plated steel seal structure calibration External gain adjustment Built-in programming voltage - Overvoltage protection 5 V Reference voltage Built-in thermal shutdown function
- Application:
- Electrophoretic capacitor Charging field generation spectroscopy analysis Deflector plate test device Video multiplier tube
Spec
- Quantity: 1 piece
- Output Voltage: 10 kV
- Input voltage range: 11.5 to 16 V dc
- Rating Power: 1W
- Output current: 100 microA
- Number of outputs: 1
- Minimum temperature: -10 degrees C
- Maximum temperature: + 60 degrees C
- MTBF Average Failure interval: > 2.6 million h
- RoHS compliance status: Compliance
- Securities Code: 123 -8388
