63-6905-71 Thin-film Chip Resistor 1005 size 0.063 W 1.54 kohm +/- 0.1% CPF0402B1K54E1
model:
63-6905-71
brand:
TE Connectivity
Product Description
Product Model: 63-6905-71Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-6905-71
Product Brand: TE Connectivity
Features
- TE Connectivity CPF Series 0402 Precision Resistors (560 Ω → 1.96 kΩ)
- CPF precision resistors consist of an alumina substrate and a nichrome (NiCr) resistive layer. 100% matte electrotin-plated finish. With a variety of standard case sizes, this chip resistor has uniformly accurate dimensions for easy placement. TE Connectivity's CPF series thin film precision resistors offer high stability and precision. This chip resistor has a resistance tolerance of at least 0.1% and a temperature coefficient of resistance (TCR) value as low as 15 ppm/°C.
- Features • Product application information • High accuracy • High stability • Accurate dimensions • Temperature range: -55 → +155 °C • Various resistance values to suit all applications • Suitable applications for CPF precision resistors include communications, industrial control, instrumentation, and medical applications.
Spec
- Quantity: 1 reel (1000 pieces)
- Resistance: 1.54 kohms
- Package/Case: 0402
- Tolerance: +/- 0.1%
- Rated power: 0.063 W
- Temperature factor: +/- 25 ppm/deg.
- Technology: Thin film
- Dimensions: 1 x 0.5 x 0.35 mm
- Length: 1 mm
- Depth: 0.5 mm
- Height: 0.35 mm
- Series: CPF
- Operating temperature Min: -55 degrees C
- Operating temperature Max: + 155 degrees C
- Case Style: Mold
- RoHS compliance status: Compliance
- Securities Code: 123 -7072
