63-6901-07 Push Button Switch 3A Momentary Panel Mount Red Bipolar Double Throw (DPDT) IP 67 AV1920P312Q04
model:
63-6901-07
brand:
TE Connectivity
Product Description
Product Model: 63-6901-07Product Brand: TE Connectivity […]
Contact Us
Product Details
Product Model: 63-6901-07
Product Brand: TE Connectivity
Features
- RoHS/R units/UL certified • TE Connectivity AV19 series anti-bandal switch • TE Alcoswitch Anti-bandal switch is designed with industrial security and reliability in mind. AV19 series is a 19 mm panel mounting product. Various combination types are available, such as momentary/latch, LED display on/off, etc. The TE Alcoswitch series provides an easy-to-*** ***r interface solution for a variety of panel mounting applications.
- Features & Benefits: Shock resistant with superior appearance and usability for advanced customization. The rear mounting thin nuts provide an impact resistant design. There are various push button symbols, including the plane, ring, and power logo. Typical applications: Control and communication equipment Elevators and escalator instrumentation
Spec
- Number of pieces: 1
- How the Switch Works: Momentary
- Contact Configuration: Bipolar Double Throw (DPDT)
- Mounting Type: Panel Mount
- Panel cutout diameter: 19.2 mm
- Contact current rating: 3A
- Contact AC Rated Voltage: 250 V
- Rated voltage: 250 V ac
- Illumination: Yes
- Actuator Color: Silver
- LED Color: Red
- Operating temperature range: -20 to + 55 degrees C
- RoHS compliance status: Compliance
- Securities Code: 123 -6104
