63-6896-39 mini-MSD Connector (for Electric Vehicless) 160 A 600 to 690 V ac male Orange MINIMSDM160
Electronic/Electrical Parts and Controll Equipments

63-6896-39 mini-MSD Connector (for Electric Vehicless) 160 A 600 to 690 V ac male Orange MINIMSDM160

model: 63-6896-39
brand: Amphenol

Product Description

Product Model: 63-6896-39Product Brand: Amphenol Featur […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-6896-39
Product Brand: Amphenol

Features

  • Mini MSD Plug (with HVIL)
  • This Mini MSD (Manual Service Disconnect) from Amphenol is for charging plug-in hybrid vehicles (PHEV) and is equipped with a high voltage interlocking loop (HVIL). This plug has a two-step lever to open the HVIL circuit before separating the high-voltage contacts. The MSD allows the internal high-voltage battery pack to be shut off without the need for special tools, while also protecting the battery from short circuits. This mini MSD provides advanced intrusion protection and provides a safe and secure solution for PHEV services. It is also a more compact and cost-effective alternative to the standard MSD.
  • Features and Advantages: Durability over 50 insertions and removals Protection rating for biting: IP67, IP6K9K Operating temperature: -40°C → 70°C Standards: USCAR-2, USCAER-37, LV-215

Spec

  • Number of pieces: 1
  • Series: MINI MSD
  • Connector Type: Mini Manual Service Disconnect
  • Current rating: 160 A
  • Operating voltage: 600 to 690 V ac
  • Connector G***er: Male
  • Contact G***er: Male
  • Latch type: 2-level lever
  • RoHS compliance status: Compliance
  • Securities Code: 123 -5205
