Spec

• trace/cuvette measurement model
• < General Specifications >
• External Dimensions: 200 (W) x 290 (D) x 200 (H) mm (Including Touch Screen)
• Weight: 3.8~5.2 kg (dep***ing on configuration)
• Power: 90~250 V, 50/60Hz, 60 W
• Display: 1024 x 600 pixels
• Certification: CE, IEC 61010-1:2012, EN 61326-1:2013
• In/Out Ports: USB A x 2, USB B, HDMI, Ethernet, Wireless LAN
• Other data input: USB mo***, USB keyboard
• security: Kensington slots
• optical system specification
• Wavelength Scan Range: 200~900 nm
• Measurement time: 3.5~6.0 seconds
• Wavelength reproducibility: ±0.2 nm
• Wavelength accuracy: ±0.75 nm
• Bandwidth: 1.8 nm or more
• Stray light: <0.5% 240 nm when using Nal, <1% 280 nm when using acetone
• Measurement repeatability: <0.002 A (optical path length 0.67 mm) when using 280 nm
• Accuracy of measurement: <1.75% 0.7 A (optical path length 0.67 mm) when using 280 nm
• 0 stability: +/- 0.003 A/hour (20 minutes after warm-up when using 280 nm)
• Noise: 0.002 A rms(0 A when using 280 nm), 0.002 A (pk-pk) (0 A when using 280 nm)
• Optics: 1 x 3648 CCD Array
• Light source: xenon flash lamp
• Light source life: 10^9 flashes or more than 10 years
• < During micromeasurement >
• Detection range/dsDNA: 1 ng/μL to 16,500 ng/μL
• Detection range/BSA: 0.03 mg/mL to 478 mg/mL
• Minimum sample volume: 0.3 μL
• Measuring range: 0.02~330 A
• Optical path length: 0.67, 0.07 mm
• Dilution rate: 1/15, 1/140
• Vortex mixer: 2800rpm
• < During cuvette measurement >
• Detection range/dsDNA: 0.1 ng/μL to 130 ng/μL
• Detection range/BSA: 0.003 mg/mL to 3.7 mg/mL
• Measuring range: 0~2.6 A
• Optical path center height (Z): 8.5 mm
• Cell Type: Outer Dimensions 12.5 x 12.5 mm
• Temperature control: 37°C±0.5°C
