4-3313-11 Fume Hood (Tabletop Type/High Line Type) Deep 1200 x 900 x 1950 mm ADTC-1200
Product Description
Product Model: 4-3313-11Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-3313-11
Product Brand: AS ONE Corporation
Features
- To be installed on a side laboratory table or workbench.
- Since the internal effective height of the ASTC type is 550 mm higher than that of the desktop type (AST), it is suitable for the *** of tall equipment and instruments.
- For Acid/Alkali
- For Organic
Spec
- specifications: deep
- External Dimensions (mm): 1200 x 900 x 1950
- Inner Dimensions (mm): 950 x 675 x 1750
- Weight (approx. kg): 165
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenol Resin Laminated Board)
- Work Plane: Unattached
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (Height 400 mm), Handle/ABS Resin
- Hydrant/Outlet: Not Included
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- [Exhaust]
- Air volume (m3/min): 13
- Duct Connection Port: 200 A
- Required Duct Diameter (φmm): 200
- [Ancillary Facilities]
- Fluorescent Lamp (Pieces): 20 W x 2 Lamps Equivalent
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
