63-6864-02 Insulation DC-DC Converter Vout: ± 12 V dc 9 to 18 V dc 4 W 12 V dc JCA0412D02
Product Description
Product Model: 63-6864-02Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6864-02
Product Brand: XP Power
Features
- XP Power-JCA 4/6 Series DC-DC Converter
- The XP Power JCA 4/6 series is a reliable single/dual output 4/6W insulated DC-DC converter. 2:1 input range, in a 1.0 ” x 0.8 ” metal package with industry standard pin alignment. These compact DC-DC converters have a wide operating temperature range of -40 to +100 °C and are UL and TUV certified.
- 4/6 W Insulated DC-DC Converter Single Output and Dual Output 2:1 Input Range Compact 1.0 x 0.8 inch Metal Package -40 → +100 °C Wide Operating Temperature Range UL and TUV Certified
Spec
- Quantity: 1 piece
- Output Voltage: ± 12 V dc
- Input voltage range: 9 to 18 V dc
- Input voltage nominal: 12 V dc
- insulation Voltage: 1.5 kV dc
- Rating Power: 4W
- Output current: ± 170 mA
- Mounting type: through hole
- Number of outputs: 2
- Efficiency: 83%
- Package: DIP 24
- Road regulation: ± 1%
- Maximum temperature: + 100 degrees C
- Series: JCA
- RoHS compliance status: Compliance
- Securities Code: 122 -8712
