Electronic/Electrical Parts and Controll Equipments
63-6863-45 Insulation DC-DC Converter Vout: 12 V dc 8 to 36 V dc 3 W 24 V dc IZ2412SA
Product Description
Product Model: 63-6863-45Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6863-45
Product Brand: XP Power
Features
- XP Power-IZ Series Insulated DC-DC Converters
- The IZ series of XP Power is a reliable and stable single/dual output 3W insulated DC-DC converter. This series has a breakdown voltage of 1600 V dc and is packaged in industry-standard SIP packages. These compact DC-DC converters offer a 2:1 input range, continuous short-circuit protection, and a wide operating temperature range of -40 to +100 °C, making them ideal for a variety of commercial and industrial applications.
- Insulating Voltage Stable Single/Dual Output 2:1 Input Range of 3 W Insulated DC-DC Converter 1600 V dc SIP Package Remote On/Off -40 → Wide Operating Temperature Range of +100 °C Continuous Short Circuit Protection
Spec
- Quantity: 1 piece
- Output Voltage: 12 V dc
- Input voltage range: 8 to 36 V dc
- Input voltage nominal: 24 V dc
- insulation Voltage: 1600 V dc
- Rating Power: 3W
- Output current: 250 mA
- Mounting type: through hole
- Number of outputs: 1
- Efficiency: 82%
- Package: SIP8
- Road regulation: ± 1%
- Maximum temperature: + 100 degrees C
- Series: IZ
- RoHS compliance status: Compliance
- Securities Code: 122 -8656
