68-1071-30 Gas Chromatograph GC3210H Type S 2701-11220
Product Description
Product Model: 68-1071-30Product Brand: GL Sciences Inc […]
Contact Us
Product Details
Product Model: 68-1071-30
Product Brand: GL Sciences Inc.
Features
- Combination with packed column enables wide range detection from inorganic gas to organic components (H2 analysis is also possible by changing the carrier gas to Ar gas.)
- Touch panel for improved operability and easy status confirmation
- Equipped with oven back door (flap) for temperature control around room temperature
- The *** of a DC brushless motor makes it possible to install in offices with low noise and low vibration.
- Chromatograph for hydrogen carrier gas (optional hydrogen carrier safety kit recomm***ed)
Spec
- Detector: Thermal conductivity detector (TCD)
- Column oven specifications
- Method: Forced circulation type air thermostat
- Set temperature: 0~350°C
- Heater Capacity: 0.8 kW
- Temperature Rise Range: 50°C→350°C 15 minutes or Less (Injection port, detector heater OFF, 100 VAC, room temperature at 20°C)
- Excess Temperature Rise Prevention Function: (1) Maximum Temperature Monitoring 370°C (2) Monitoring Circuit with Monitoring Temperature Sensor Approx. 400°C
- Column oven size: 200 (W) x 160 (D) x 250 (H) mm
- Inlet: Insert Type Direct Inlet, 1 Inlet
- Body Size: 400 (W) x 420 (D) x 433 (H) mm (Excluding Protrusion)
- Power: 100 VAC, 50/60Hz, 12 A
- Body Weight: Approx. 28 kg
- *Please contact us for installation and optional items.
*This product might require extra fees.
