63-6852-16 AC/DC Converter 48 V dc 10.5 A 500 W with case Y GSP500PS48-EF
Product Description
Product Model: 63-6852-16Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6852-16
Product Brand: XP Power
Features
- XP Power-GSP500 Series AC-DC Power
- XP Power's GSP500 series offers excellent 500 W open frame power. All models are ITE certified and certified for medical ***. All models of this highly reliable compact power supply have a standard efficiency of 90% and standby power of less than 0.5 W. This power supply has a remote on/off function, a standby output power of 5 V with a current capacity of 2 A, and an operating temperature of -40 to +70 °C.
- 500 W, AC-DC Power Universal Input: 85 → 264 V ac ITE Certified and Medical Certified Operating Temperature Range: -40 → +70 °C Standby Power:; 0.5 W efficiency: 90% remote on/off standby output: 5 V/2 A EN55011/22 Level B emission standard
Spec
- Quantity: 1 piece
- Output Voltage: 48 V dc
- Output Current: 10.5 A
- Rating Power: 500 W
- Number of outputs: 1
- Input Voltage: 80 to 264 V ac
- Mounting Type: Chassis Mount
- Package Type: With Cover
- Length: 170.4 mm
- Width: 101.6 mm
- Depth: 41.9 mm
- Weight: 900 g
- Maximum temperature: + 70 degrees C
- Medical standards certification: Yes
- RoHS compliance status: Compliance
- Securities Code: 122 -7171
