Electronic/Electrical Parts and Controll Equipments
63-6851-40 AC/DC Converter 5/± 15 V dc 2.5 A 8 A 500 mA 60 W Open Frame Y ECM60UT33
Product Description
Product Model: 63-6851-40Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6851-40
Product Brand: XP Power
Features
- XP Power-ECM60 Series AC-DC Power Supply
- The XP Power ECM60 Series offers a variety of open-frame 60 W AC-DC power supplies. All of these products are approved by the IT/Healthcare industry. All of these reliable, compact power supplies have a Class I or Class II structure. This series of products is convectively cooled and has an operating temperature range of 0 to +70 °C.
- Open-frame, 60 W power efficiency: 80 ~ 85% IT/Healthcare approved Class I/Class II structural DC input version available (DCM series) 3 year warranty
Spec
- Quantity: 1 piece
- Output Voltage: 5/± 15 V dc
- Output Current: 2.5 A, 8 A, 500 mA
- Rating Power: 60 W
- Number of outputs: 3
- Input Voltage: 120 to 370 V dc, 90 to 264 V ac
- Mounting Type: Chassis Mount
- Package Type: Open Frame
- Length: 101.6 mm
- Width: 50.8 mm
- Depth: 27 mm
- Weight: 150 g
- Maximum temperature: + 70 degrees C
- Minimum temperature: 0 degrees C
- RoHS compliance status: Compliance
- Securities Code: 122 -7092
