63-6850-20 Insulation DC-DC Converter Vout: 5 V dc 21.6 to 26.4 V dc 2 W 24 V dc IL2405S
Product Description
Product Model: 63-6850-20Product Brand: XP Power Featur […]
Contact Us
Product Details
Product Model: 63-6850-20
Product Brand: XP Power
Features
- XP Power-IL Series Insulated DC-DC Converter
- The IL series of XP Power is a reliable single-output 2W insulated DC-DC converter. The breakdown voltage is 1000 V dc and is provided in industry-standard SIP packages. Each of these compact DC-DC converters has a wide operating temperature of -40 to +85 °C and a maximum efficiency of 84%.
- 2 W Insulated DC-DC Converter with Insulation Voltage 1000 V dc, 3000 V dc Option Single Output Operating Temperature Range: -40 → +85 °C Industry Standard SIP Packaging Maximum Efficiency: 84%
Spec
- Quantity: 1 piece
- Output Voltage: 5V dc
- Input voltage range: 21.6 to 26.4 V dc
- Input voltage nominal: 24 V dc
- insulation Voltage: 1 kV dc
- Rating Power: 2W
- Output current: 400 mA
- Mounting type: through hole
- Number of outputs: 1
- Efficiency: 80%
- Packages: SIP
- Road regulation: ± 10%
- Maximum temperature: + 85 degrees C
- Series: IL
- RoHS compliance status: Compliance
- Securities Code: 122 -6967
