61-7649-26 Mold Temperature Control Fitting Straight R1/8 ASC10-601
Product Description
Product Model: 61-7649-26Product Brand: NIHON PISCO CO. […]
Contact Us
Product Details
Product Model: 61-7649-26
Product Brand: NIHON PISCO CO., LTD.
Features
- One-touch joint for mold cooling.
- Three types of fluids are ***d: oil, water (fresh water) and air.
- When the plug is removed, no protrusions remain in the mold.
- The stop valve built-in type prevents hot water from flowing out when the plug is detached.
Spec
- Fluid ***d: Air
- Fluid ***d: Water (freshwater), heat medium oil (*1. water, When you *** heat medium oil, Keep surge pressure to the maximum operating pressure or less. 2. Water, When you *** heat medium oil, Using an insert ring is recomm***ed. )
- Maximum operating pressure: 0.9MPa
- Used vacuum pressure (air only): -100kPa
- Operating temperature range: Air: 0 - 60℃ (no freezing), Water (springwater): 0 - 99℃ (no freezing) Heating medium oil: 0 - 120℃ (no freezing)
- Shape: Internal stop valve type, straight
- Fitting shape: Straight
- Series name: 10 series
- Applicable tube size: One touch fitting type (outer diameter): φ6mm
- Applied screw size: R1/8
- Set product of plug and socket
