Spec

• Dimensions ( mm ) : Φ 21
• Mass (g/m ^ 2): 60
• Thickness (mm): 0.15
• Pressure drop (kPa): 0.44
• Collection efficiency (0.3 μm DOP%): 99.95
• Water repellency (kPa): ≥ 7.8
• Moisture absorption (mg): 0.11
• Binder: Fluorine Plastic Binder
• Maximum operating temperature (°C): 260
• *Pressure drop ・・・ value at a ventilation rate of 5 cm/s.
• *Collection Efficiency ・・・ 0.3 Collection efficiency when air containing dispersed dioctyl μm phthalate particles is filtered through an aeration rate of 5 cm/s.
• *Water Repellency ・・・ Pressure required for water to pass through.
• *Moisture Absorption ・・・ In accordance with JIS K 0901, "Shape, Dimensions and Performance Test Method of Filter Material for Collecting Dust Samples in Gas", the amount of moisture absorbed after 24 hours in an atmosphere of 90% humidity was measured with a 47 mm sample in diameter.
• *Moisture absorption is a reference value based on actual measurement.
• *The maximum operating temperature dep***s on conditions such as pressure and time, so please *** it as a guide.
