4-1184-21 Fume Hood (HEPA Filter Built-in Type) Standard 1200 x 830 x 2250 mm ABS-1200HP
Product Description
Product Model: 4-1184-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-1184-21
Product Brand: AS ONE Corporation
Features
- A fume hood suitable for powder work with a HEPA filter attached to the back of the baffle plate.
- The air volume display function is provided as standard, and the exhaust condition can be checked and operated.
- The sash is of the left and right sliding type and the work frontage can be taken high, making it suitable for measuring work.
- For Acid/Alkali
- For Organic
Spec
- Specifications: Standard
- External Dimensions (mm): 1200 x 830 x 2250
- Inner Dimensions (mm): 950 x 510 x 1200
- Weight (approx. kg): 270
- Control wind speed: 1.0 m/s (Opening height of sash at work: 700 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Filter: High Air Volume HEPA Filter/Pre-Filter
- Sash: Tempered Glass (5 mm Thickness) Left-Right Slide Type
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
