Spec

• Validated products are Azuwan original services that conduct FAT (Factory Acceptance Test) at Azuwan before shipping.
• Validate (FAT) before shipping.
• After receiving the order, a FAT instruction form (plan) is sent to the ***r, and after the signature is returned, the FAT is performed.
• App***ix: FAT report/Calibration Certificate of ***d measuring instrument copied
• *I am attaching Azwan's original FAT instruction manual (see the sample at the bottom left of the Screen).
• Temperature point: 1 point of 550 degrees Celsius
• Maximum temperature (deg. C): 550
• Plate size (mm): 175 x 178
• Type: Analog
• Material: Plate/Ceramic, Body/Aluminum die cast (heat resistant coating)
• Temperature control method: PID control with K thermocouple
• Heater capacity: 900 W
• Safety device: Overcurrent f***, Internal temperature f***, High temperature warning display function
• Power supply: 100 VAC 50/60 Hz
• Heating plate size (mm): 155 x 159
• Size: 194 x 292 x 104 mm
• Weight: 2.5 kg
• This product can be inspected and inspected.　Please contact us.
• *Inspection Certificate service is a service that carries out inspections of the control relation (measured temperature inside the wareho***, etc.) and the power engine personnel at the time of shipment or at the customer's site, and issues inspection documents.
• *If you would like to request a local IQOQ, please contact us separately. We will need your installation address for the estimate.
